What kind of UPS does under R3,000 actually buy?

A line-interactive unit with a sealed lead-acid battery, generally in the 650VA to 1200VA class and built around a single internal 12V cell. That topology brings automatic voltage regulation, so mild sags and swells get corrected without discharging anything. Double-conversion designs and lithium chemistry are priced above this bracket.

How many minutes will one run a desktop and monitor?

Expect single figures under a gaming load. A tower drawing three to four hundred watts empties an entry battery quickly, and the discharge curve steepens as load rises, so a model quoted at twenty minutes on a light office machine may manage five on a rig with a large graphics card. Read the figure as time to save and power down.

Do I need to connect it to the PC with a cable?

Only if you want the machine to shut itself down while nobody is there. A unit with a USB data port reports its battery state to the operating system, which can then close applications and power off before the charge runs out. Without that cable the runtime helps only when somebody is sitting at the desk.

Why does my PC still shut down the moment the UPS takes over?

Two causes dominate at this price. The unit may be pushed past its watt rating by the machine, monitor and peripherals together, in which case it trips instead of browning out. The other is waveform: budget models synthesise a stepped approximation of mains, and a power supply with active correction can read that as a fault and drop out during the transfer, often buzzing audibly first.

Will my plugs fit the sockets on the unit?

Check before ordering, because three fittings are in circulation locally. Older units carry the large three-pin outlets, newer ones use the smaller standard now specified for new installations, and many imported models offer only IEC outlets that take a kettle lead. A PC and monitor cope happily with IEC; a printer or desk lamp with a moulded plug does not, and adapters add a failure point in the middle of the chain.

Can I replace the battery when it wears out?

Usually yes, since these units take standard sealed lead-acid cells in common 7Ah and 9Ah sizes with spade terminals. That chemistry gives roughly three to five hundred cycles and dislikes deep discharge, so a unit riding out frequent long interruptions ages faster than one that sees a few dips a month. Match voltage, capacity and terminal type, and weigh the replacement cost against the price of a whole new unit.

Does it do anything useful while the power is on?

The regulation circuit works constantly. Local suburban feeds sag when a whole neighbourhood restores load at once and drift upward late at night when demand falls away, and a line-interactive unit trims both back towards nominal without touching the battery. Over several years that quiet correction is arguably worth more to a power supply than the handful of battery minutes.

►Specials

►Best Sellers

►UPS

►

UPS Under R3000 South Africa

Compact line-interactive UPS standing beside a desktop tower and a fibre router

What a Sub-R3,000 Unit Can and Cannot Do

At this price you are buying a small line-interactive box with a sealed lead-acid battery inside, and its job is narrow. It bridges the moment supply drops and buys enough time to save open files and close the machine down in an orderly way. Most buyers here are protecting one desktop, a monitor and the fibre equipment next to it. An abrupt cut costs more than the session: writes still in flight can leave a filesystem inconsistent, a firmware update interrupted mid-flash can leave a board refusing to boot, and repeated hard restarts wear the power supply.

Two figures decide whether a model suits you, and the larger one is the less useful. Volt-amps lead the marketing; the watt rating printed alongside is the real ceiling, and entry units commonly publish pairs such as 650VA with 360W. Add up the genuine draw of everything you intend to attach, remembering that a desktop under load pulls several times what it does sitting idle at the desktop wallpaper.

Socket fitment is a local complication worth checking before you order, because some units present the older large three-pin outlets, newer ones the smaller standard now specified for fresh installations, and many imported models only IEC outlets that need kettle leads. Scheduled national outages are behind us, yet suburban feeds still fail for planned maintenance, cable faults and storm damage, without notice and without a published timetable. Evetech dispatches from Centurion.

Choosing Backup Power When the Budget Is Fixed

A hard price cap turns the question from which unit is best into which compromises you can live with. What you are really choosing at this level is a topology, a battery size and a socket layout; the rest is packaging and a display.

The volt-amp number leads because it is bigger. The figure that governs what you can attach is the watt rating beside it, and entry models publish pairs such as 650VA with 360W or 850VA with 510W. Leave headroom for the millisecond current spikes a modern graphics card produces during load transitions, because an overloaded unit at this level protects itself by cutting the output rather than riding through.

Online double-conversion designs, which run the load permanently from the inverter, sit well above this bracket, as do lithium cells and the larger pure sine models. Expansion goes too: network management cards, extra battery packs and rack mounting all belong to higher tiers. What survives the cut is the part that matters most on a home desk, namely voltage regulation and a battery sized for a shutdown.

Many units split their sockets into two banks, one fed by the battery and one carrying surge suppression alone, with the labelling moulded into the plastic rather than printed. Putting the tower on the surge-only side is a common mistake that stays invisible until the day it matters. Count the battery-backed outlets, and check the spacing as well, since two plug-in adapters side by side will block a neighbouring socket.

Cold start lets the unit energise its outlets from the battery when there is no mains present at all. Without it, arriving home to a dead street means the box sits holding a charge it will not release, and the router stays down until supply returns. It is usually a button held for a few seconds, and it is worth confirming the model in front of you has one.

A lead-acid unit in this class weighs several kilograms because the battery is most of it, so whatever shelf or bracket carries it needs to take that. The relay clicks audibly each time regulation engages, which on a weak suburban feed can happen several times in an evening. The outage alarm is deliberately loud and often cannot be silenced from the front panel, although the bundled monitoring software usually can.

Decide which machine has to survive the cut before comparing models, because a desktop and a fibre router are opposite problems sitting in the same catalogue.

Choosing Backup Power When the Budget Is Fixed

Decide which machine has to survive the cut before comparing models, because a desktop and a fibre router are opposite problems sitting in the same catalogue.

What a Sub-R3,000 Unit Can and Cannot Do
